Phono Cartridges
Ortofon MC Quintet Bronze wstecz
Ortofon MC Quintet Bronze wkładka gramofonowa

MC Quintet Bronze



Quintet Bronze moves into the higher league of the Quintets. The slim profile of its Nude Fine Line diamond stylus will track even the highest frequency information, making it a must for discerning listeners. Additionally its larger footprint ensures reduced distortion and record wear. The sound will be very evenhanded with respect to all aspects. Classical music will be reproduced with power and open space around each of the instruments. All types of music will be conveyed with the highest accuracy, precision and Dynamics.



Technical data:

Output voltage at 1000 Hz, 5cm/sec.  0.3 mV

Channel balance at 1 kHz  < 1.2 dB

Channel separation at 1 kHz  > 23 dB

Channel separation at 15 kHz  > 15 dB

Frequency range at - 3dB  20-25.000 Hz

Frequency response 20-20.000 Hz  +/-1.5 dB

Tracking ability at 315Hz at recommended tracking force *)  80 µm

Compliance, dynamic, Lateran  15 µm/mN

Stylus type  Nude Fine Line

Stylus tip radius  r/R 8/40 µm

Tracking force range  2.1-2.5 g (21-25 mN)

Tracking force, recommended  2.3 g (23 mN)

Tracking angle  20°

Internal impedance, DC resistance   5 Ohm

Recommended load impedance   > 20 Ohm

Cartridge body material   ABS/Aluminium

Coil wire material  Pure 4-nines copper

Cartridge colour  Bronze

Cartridge weight   9 gram

*) Typical value



BRAND-NEW item

Price: 3 199,00 zł



Availability: Yes



Sending: 5 days
